Radkutsche MUSKETIER: Dreirädriges Schwerlastenrad mit hoher Zuladung

Wheeled carriage MUSKETEER

stable workhorse

The MUSKETIER cargo bike belongs to the category of heavy-duty bicycles. This type of cargo bike is designed primarily for commercial use. What makes the Musketier special is the wide range of body options available, covering a broad spectrum of applications. Combined with a payload of over 200 kg (including rider) and up to 2 m² of cargo space in the Muskebox, the cargo volume is equivalent to that of a small van. This load is best moved with the assistance of the hub motor in the front wheel. At just 1 m wide, the MUSKETIER remains pleasingly narrow, allowing for easy use of the existing bicycle infrastructure, avoiding inner-city traffic jams.


As an e-cargo bike with a large 23.45 Ah battery (manufacturer: Smart Battery Solutions) and a 250 W hub motor in the front wheel, a matching trailer is also available upon request. While the MUSKETIER is also available without an electric drive, we recommend the manual version without an electric drive only for flat terrain or with light loads.


Tip for all business owners in NRW: Funding of up to 45% is possible, further details can be found here.

Technical data wheeled carriage MUSKETEER

Wheeled carriage MUSKETEERS
Frame hand-welded, robust tubular steel frame
Long 2560 mm< (abhängig vom Aufbau)
Width (handlebar) 1000-1100 mm (depending on the selected hub)
Platform height 450 mm
Empty weight 68 kg
maximum weight allowed 300 kg
Transport volume up to 2 m²
Maximum permissible rider weight 120 kg
Electric drive DC brushless hub motor 250w with planetary reduction gear
Top speed <25 km/h (abgeregelte Motorunterstützung)
trailer hitch upon customer request
Musketeer Pendant upon customer request
  • Radkutsche MUSKETIER: Ohne Aufbau

    Image title

    Radkutsche Musketier ohne Aufbau: Viel Platz für deine persönliche Idee.

    Button
  • Radkutsche MUSKETIER mit großer Pritche 150

    Image title

    Die Pritche 150 macht dein MUSKETIER zum nachhaltigen Pick-Up

    Button
  • Radkutsche MUSKETIER mit Muskebox

    Image title

    Die Muskebox bietet dir massig Platz für Transporte aller Art.

    Button
  • Radkutsche MUSKETIER mit Rikscha Aufbau für zwei Erwachsene

    Image title

    Das Musketier ist eines der wenigen Lastenrädern mit Rikscha- Aufbau.

    Button
  • Radkutsche MUSKETIER mit Müllcontainer

    Image title

    Der Müllcontainer, optional mit Deckel, macht dein Musketier zum nachhaltigen Entsorgunsfahrzeug

    Button
  • Radkutsche MUSKETIER mit Caretaker

    Image title

    Der Caretaker ermöglicht dir schnelle Mobilität im Park.

    Button
  • Radkutsche MUSKETIER mit Küchenaufbau

    Image title

    Der Gastroaufbau, im Bild beispielhaft dargestellt, ermöglicht dir hohe Flexibilität.

    Button
  • Radkutsche MUSKETIER mit Kühlbox

    Image title

    Die Ice-Box One sorgt für dauerhaft Kühlung bis -18°. Perfekt in Kombination mit einem Küchenaufbau.
